Trigger Systems Triton TRITON20C-V2
The TRITON2OC has 3 main sections. Water enters the sump through the input fittings. Water then flows through the large refugium section that has a lid to prevent noise and water evaporation. Water then flows towards the front of the sump and then to right through the overflow teeth in the adjustable wall into Section 2.
Section 2 is typically where the protein skimmer is located. Water purposely exits Section 2 by flowing under the aquamarine wall to allow proteins to remain at the surface maximizing the potential for the protein skimmer to extract from the system. The water then flows through the media platform and foam filter block into Section 3. The media platform can be used to allow for several different filtration methods (bag of carbon, bio balls, bio media, rubble rock, etc.).
Section 3 is the return section where the return pump will sit, pumping water back to the display tank.
Trigger Systems Triton TRITON20C-V2
The TRITON2OC has 3 main sections. Water enters the sump through the input fittings. Water then flows through the large refugium section that has a lid to prevent noise and water evaporation. Water then flows towards the front of the sump and then to right through the overflow teeth in the adjustable wall into Section 2.
Section 2 is typically where the protein skimmer is located. Water purposely exits Section 2 by flowing under the aquamarine wall to allow proteins to remain at the surface maximizing the potential for the protein skimmer to extract from the system. The water then flows through the media platform and foam filter block into Section 3. The media platform can be used to allow for several different filtration methods (bag of carbon, bio balls, bio media, rubble rock, etc.).
Section 3 is the return section where the return pump will sit, pumping water back to the display tank.
- Dimensions: 20″ long x 20″ wide x 15″ high
- Refugium Section: 19.5″ x 9.25″ (9 gallons)
- Skimmer Section: 10″ x 11″
- Return Pump Section: 6″ x 10″
- Total Water Volume: 24.3 gallons
- Refugium Water Level: 8″ to 11.5″
- Skimmer Water Level: 7″ to 9.5″ adjustable
- Drain Input Fittings: 1″ (x3)
Product code: 7489
Item No. FT-TS-TRITON20C-V2
