4-Head Dosing Pump

Simplicity 4-Head Dosing Pump – Accurate, Effective, and Affordable

• 4 Individually Programmable Pumps
• Compact, Space Saving Design
• Multiple Mounting Options
• Custom-label Each Pump Head

The Simplicity Dosing Pump is an accurate, effective, and affordable liquid dosing solution. The four dosing heads offer high-precision liquid dosing combined with easy-to-use integrated controls. The compact, space-saving design can be flush mounted to a wall or placed on a shelf. The included pump head labels make identifying dosing solutions easy.

The Simplicity 4-Head Dosing Pump is also compatible with all Simplicity dosing containers and accessories like dosing tube holders and colored silicone dosing pump tubing. All of which can be found here.

Specifications:

• 7.9” L x 3.0” W x 4.0” H
• Power Consumption: 7.5W
• Power Input: 12V DC
• Power Cord Length: 5 ft
• 3-year manufacturer prorated warranty

Pump Specifications:

• Control Interval: From once per hour to once every 30 days
• Flow Rate: 50 mL per minute
• Maximum Head Pressure: 5 ft
• Accuracy: +/- 0.1 mL per 10 mL
• Dosing Volume: From 1 mL up to 9999 mL

What’s in the Box?

• Simplicity 4-Head Dosing Pump
• Power Supply
• Pump Head Labels
• Measuring Cup
• Check Valves (5x)
• Mounting Screws (2x)
• Spare Pump Head
• Mounting Template
